Free Oil Refinery Flow Chart
The Oil Refinery Flow Chart offers a detailed, condition-based roadmap for transforming crude oil into refined, market-ready products. It begins with the receipt and desalting of crude oil, followed by a water quality check that determines whether contaminants are present. If impurities are detected, the flow initiates amine treatment and sulfur recovery before continuing. The chart then evaluates the complexity of the cracking process, guiding operations toward either catalyst regeneration and hydrotreating or direct distillation. Residual materials trigger vacuum distillation and further treatment, ensuring maximum yield and minimal waste. Once refined, products are blended and stored, completing the cycle. Each decision point ensures that treatment paths are tailored to the oil’s condition, reinforcing efficiency, safety, and environmental compliance throughout the refining process.
